Dimensions
|
|
|
Power
|
|
|
Headshaft Height
|
13.7 in.
|
|
Engine
|
Honda® GX690
|
|
Length ( up to )
|
94 in.
|
|
Fuel
|
Gasoline
|
|
Width, transport
|
35.8 in.
|
|
Cooling Medium
|
Air
|
|
Height, transport ( up to )
|
63 in.
|
|
Number of Cylinders
|
2
|
|
Centerline Trench to outside edge machine
|
|
Manufacturer's Net Horsepower Rating
|
22 hp
|
|
Left
|
17.2 in.
|
|
Rated Speed
|
3,600 rpm
|
|
Right
|
18.6 in.
|
|
Fuel Consumption @ rated power
|
1.77 gph
|
|
Power Train
|
|
|
Operation
|
|
|
Ground Drive Transmission
|
Hydraulic, infinite variable from zero to maximum, speed and direction control
|
|
Vehicle Speeds, Max
|
|
Transit Forward
|
176 fpm
|
|
Transit Reverse
|
136 fpm
|
|
Digging Chain Drive
|
Hydraulic direct drive, one speed forward and reverse
|
|
Digging Chain Speed
|
|
Pump Drive
|
Direct drive from engine
|
|
19K
|
366 fpm
|
|
Track Width
|
8 in.
|
|
33/35K
|
309 fpm
|
|
Trencher Drive
|
|
Spoil Handling
|
|
Hydraulic
|
Direct Drive
|
|
Auger, Type
|
Single, Open End
|
|
Digging Chain
|
19K, 33K, and 35K
|
|
Auger, Diameter
|
17 in.
|
|
Ground Pressure
|
4.5 psi
|
|
Trench Cleaner Type
|
Mechanical
|
|
Hydraulic System @ 3,600 RPM
|
|
Trench Cleaner Size
|
4-6 in.
|
|
Digging Drive Pump Capacity
|
10 gpm
|
|
Operating Weight ( up to )
|
1,915 lb
|
|
Filtration
|
10 micron absolute
|
|
Fuel Capacities
|
|
|
Trench Size, MAX
|
|
|
Fuel Tank
|
6.2 gal
|
|
Depth
|
36 in.
|
|
Engine Oil
|
1.8 qt
|
|
Width
|
6 in.
|
|
Hydraulic System
|
11 gal
|
|
Noise Level
|
|
|
Vibration Level
|
|
|
Ear Sound Pressure
|
91 dBA ISO 6394
|
|
Operators Hand Less than 2.5 m/s2
|
|
Overall Sound Pressure
|
100 dBA per ISO 6393
|
|
|
|
