Performance
|
|
|
Standard Specifications
|
|
|
Platform Height
|
60 ft 3 in
|
|
Power Source
|
|
Horizontal Outreach
|
49 ft 6 in
|
|
Dual Fuel Engine
GM Vortex 3000 MPFI
|
82 hp
|
|
Swing
|
360° Continuous
|
|
Diesel Engine
Deutz TD 2.9 L4
|
67 hp
|
|
Restricted Platform Capacity
|
1,000 lb
|
|
Fuel Tank Capacity
|
40 gal
|
|
Weight
|
21,800 lb
|
|
Hydraulic System
|
|
Max Ground Bearing Pressure
|
67 psi
|
|
Capacity
|
32 gal
|
|
Drive Speed 2WD
|
4.25 mph
|
|
Auxiliary Power
|
12V DC
|
|
Drive Speed 4WD
|
4.25 mph
|
|
Tires
|
|
Gradeability 2WD
|
30%
|
|
Standard
|
39 x 15-225 Lug Tread
|
|
Gradeability 4WD
|
45%
|
|
Standard Features
|
|
|
Axle Oscillation
|
8 in.
|
|
Oscillating Axle
|
Hydraulic Platform Rotator
|
|
Turning Radius 2WS (inside/outside)
|
7 ft 4 in/ 17 ft 7 in
|
|
110 AC Recetacle in the Platform
|
5 Degree Title Alarm/ Indicator Light
|
|
Turning Radius 4WS (inside/outside)
|
4 ft 7 in / 9 ft 6 in
|
|
Swing-Out Engine Tray
|
12 V DC Auxiliary Power
|
|
Accessories & Options
|
|
|
Hourmeter
|
Control ADE® System
|
|
36 x 72in Platform
|
Fall Arrest Platform
|
|
All Motion Alarm
|
Proportional Controls
|
|
Inward Swinging Cable
|
Mesh to Top Rail Bolt-on Aluminum 6ft or 8ft
|
|
Gull-Wing Hoods
|
Platform Console Machine Status
|
|
Soft Tought System
|
Operators Tool Tray
|
|
Engine Distress Warning/Shutdown
|
|
|
Tow Package
|
43.5 lb Propane Tank
|
|
|
|
|
Cold Weather Start Kit (GM or Deutz)
|
Hostile Environment Kit
|
|
|
|
|
Light Package
|
Platform Worklights
|
|
|
|
|
Flashing Amber Beacon
|
Lifting/Tie Down Lugs
|
|
|
|
