Performance
|
|
|
Standard Specifications
|
|
|
Rated Capacity
|
10,000 lb
|
|
Engine
|
|
Maximum Lift Height
|
43 ft
|
|
Make and Model
|
Cummins QSF3.8L Tier 4 F
|
|
Load at Max Height
|
7,000 lb
|
|
No. of Cylinders
|
4
|
|
Maximum Forward Reach
|
30 ft 5 in
|
|
Displacement
|
232 cu in.
|
|
Load at Max Reach
|
2,700 lb
|
|
Gross Power Basic
|
110 hp
|
|
Frame Leveling
|
10°
|
|
Maximum Torque @ 1500 rpm
|
348 lb-ft
|
|
Lift Speed ( boom retracted) Up
|
13 sec
|
|
Fuel Tank Capacity
|
38.3 gal
|
|
Lift Speed ( boom retracted) Down
|
9 sec
|
|
Transmission
|
|
Boom Speed Extended
|
15 sec
|
|
Power shift 4-speed forward
|
Power shift 3-speed reverse
|
|
Boom Speed Retracted
|
13 sec
|
|
Axles
|
|
Top Travel Speed ( 4-speed )
|
19 mph
|
|
Trunnion mounted planetary steer axles
|
Integral steer cylinder
|
|
Drawbard Pull ( loaded ) |
24,912 lb
|
|
High bias limited slip differential on front axle
|
|
|
Outside Turning Radius
|
12 ft
|
|
Brakes
|
|
Operating Weight
|
26,235 lb
|
|
Standard
|
400 /75 - 28
|
|
Accessories & Options
|
|
|
Optional
|
Foam-Filled or Solid
|
|
Enclosed Cab
|
Auxiliary Electrics
|
|
Cab
|
|
Road Lights
|
Air Conditioning
|
|
Certified ROPS/FOPS structure
|
Adjustable Seat
|
|
Work Lights
|
Rotating Reacon
|
|
Horn
|
Single joystick controls
|
|
Hydraulic Coupler
|
Fenders
|
|
Tilt & Declutch on joystick
|
Anti-Theft
|
|
Brick Guards
|
Multi-Function display with reversing camera
|
|
Steering 4-Wheel
|
|
Ride Control
|
Reverse Sensing System
|
|
Power Steering with Manual Backup
|
Operator selectable 4-wheel cycle, 2 wheel cab, 2 wheel front
|
|
Boom Brushes
|
Secondary Steering
|
|
Instruments
|
Wiper Package
|
|
|
Volt Meter
|
Hourmeter
|
|
|
|
Engine Out Pressure Gauge
|
Temperature Gauge
|
|
|
|
Fuel Gauge
|
DEF gauge
|
|
|
|
Hydraulic System-Implement Capacity
|
40 gal
|
