Backhoe Dimensions
|
|
|
Engine
|
|
|
Load Height - STD
|
10 ft. 11 in.
|
|
Make
|
John Deere
|
|
Load Height - EXT
|
13 ft. 11 in.
|
|
Model
|
John Deere PowerTech Plus 4045HT073 turbocharged
|
|
Reach From Center of Swing Pivot - STD
|
17 ft. 10 in.
|
|
Non- Road Emissions Standards
|
EPA Interim Tier 4/EU Stage IIIB
|
|
Reach From Center of Swing Pivot - EXT
|
21 ft. 5 in.
|
|
Net Peak Power
|
88 hp
|
|
Reach from Center of Rear Axle - STD
|
21 ft. 4 in.
|
|
Displacement
|
276 cu. in.
|
|
Reach from Center of Rear Axle - EXT |
21 ft. 4 in.
|
|
Net Peak Torque
|
276 lb. ft.
|
|
Bucket Cylinder Dig Force - STD
|
11,106 lb.
|
|
Electrical System
|
12 volt with 120 amp alternator
|
|
Crowd Cylinder Dig Force
|
7,006 lb.
|
|
Cooling Fan
|
Electronically controlled, variable-rate suction type
|
|
Dig Depth - STD
|
14 ft 3 in
|
|
Hydraulics
|
|
|
Dig Depth - EXT
|
17 ft 11 in
|
|
Main Pump
|
Open Center, Single Gear
|
|
Stabilizer Width, Transport
|
7ft 2in
|
|
Backhoe Pump Flow @ 2200 rpm
|
28 gpm
|
|
Stabilizer Spread. Operating
|
10 ft 2 in
|
|
Loader Pump Flow @ 2200 rpm
|
28 gpm
|
|
Stabilizer Overall Width, Operating
|
11ft 7 in
|
|
Backhoe System Relief Pressure
|
3625 psi
|
|
Bucket Rotation
|
190 degrees
|
|
Loader System Relief Pressure
|
3200 psi
|
|
Transport Height
|
11 ft 3 in
|
|
Capacities
|
|
|
Overall Length, Transport
|
23 ft 3 in
|
|
Hydraulic Oil Filter, Spin-On Enclosed Replaceable Element
|
6 micron filtration; 1,000 break-in/service hours
|
|
Width Over Tires
|
7ft 2 in
|
|
Cooling System
|
34.8 qt
|
|
Length From Axle to Axle
|
6ft 11 in
|
|
Cooling System Rear Axle |
19 qt
|
|
Operating Weights
|
|
|
Engine Oil
|
13.7 qt
|
|
Base Weight
|
14,030 lb
|
|
Torque Converter And Transmission
|
16 qt
|
|
|
|
|
Fuel Tank
|
41 gal
|
|
|
|
|
Hydraulic System
|
23.6 gal
|
|
|
|
|
Hydraulic Reservoir
|
9.8 gal
|
